BS 5 Eco

Maximum sealing:
400 × 285 mm

Maximum shell height:
150 mm

Cycles:
5 - 10 / Min.*

External dimensions:
580 × 855 × 570 mm**

Maximum film width:
420 mm

Compressed air supply:
6 Bar

Weight:
58 kg

Electrical connection:
1 phase, 230 V, 50 Hz***

Power:
1,25 kW

* Depending on the set process parameters
** w × d × h
*** Special voltages on request

INFO

Product catalog
2.1 MB, PDF-File

Sealing

Sealing plates usage	icon1fache single	icon2fachs double	icon3fachs triple	icon4fachs fourfold
Max. with contour cut	380 × 275	175 × 275	112 × 275	80 × 275
Max. without contour cut	400 × 285	195 × 285	127 × 285	95 × 285

Sealing plates usage	icon2fachw double	icon4fachw fourfold	icon6fachw sixfold	icon8fachw eightfold
Max. with contour cut	380 × 130	175 × 130	112 × 130	✕
Max. without contour cut	400 × 140	195 × 140	127 × 140	95 × 140

Sealing plates usage	icon1fachr single	icon2fachr double	icon3fachr triple	icon6fachr sixfold
Max. with contour cut.	ø 275	ø 175	ø 112	ø 100
Max. without contour cut.	ø 285	ø 200	ø 127	ø 125

w × d (in mm)
ø (in mm)
